24C32
FEATURES
Low voltage and low power operations: VCC = 1.8V to 5.5V AT24C32N/64N: Maximum Standby current < 1μA (typically 0.02μA and 0.06μA @ 1.8V and 5.5V respectively). 32 bytes page write mode. Partial page write operation allowed. Internally organized: 4,096 × 8 (32K), 8,192 × 8 (64K). Standard 2-wire bi-directional serial interface. Schmitt trigger, filtered inputs for noise protection. Self-timed Write Cycle (5ms maximum). 800 kHz (5V), 400 kHz (1.8V, 2.5V, 2.7V) Compatibility. Automatic erase before write operation. Write protect pin for hardware data protection. High reliability: typically 1, 000,000 cycles endurance. 100 years data retention. Industrial temperature range (-40℃ to 85℃). Standard 8-lead DIP/SOP/ MSOP/TSSOP/DFN and 5-lead SOT23/TSOT23 Pb-free packages.
DESCRIPTION
The AT24C32N/64N series are 32,768/65,536 bits of serial Electrical Erasable and Programmable Read Only Memory, commonly known as EEPROM. They are organized as 4096/8192 words of 8 bits (one byte) each. The devices are fabricated with proprietary advanced CMOS process for low power and low voltage applications. These devices are available in standard 8-lead DIP, 8-lead SOP, 8-lead MSOP, 8-lead TSSOP, 8-lead DFN, 5-lead SOT23, and 5-lead TSOT23 packages. A standard 2-wire serial interface is used to address all read and write functions. Our extended VCC range (1.8V to 5.5V) devices enables wide spectrum of applications.
